Block, RF Assembly 16RF with 4 Cables - Cassini

Matrix Fixture Bottom plate - RF cable top load, diags, engineering. Allows for fixed and movable cables

Part Number: RIK0161A

In Stock: 0

Estimated Restocking Time: 12+ weeks (limited)

$630

Fixture block used to interface with corresponding RF TIM. Has locations for up to 16 RF connectors.

Includes QTY 4, conformable cables 8" (#12F-SMA transient 2ea & #12F-#12F conf captive 2ea.)


Replace with these kits
RIKDesciptionQTY
Product Catalog
168ARF Block Assembly 16RF - Cassini1
Product Catalog
169ARF Cable (Coax,CONFRM,#12F-#12F 8" COAX) QTY 12
Product Catalog
170ARF Cable (Coax,Confrm,#12F special-SMAM,8") QTY 12
May replace RIK0143A for fixed cable configuration

Contact Support for assembly instructions.
Item Ref Part Number QTY Description Category Qty in Stock
1M6JGTV1A1WASHER, LOCK, #4 SPLIT, SSHrdwr
2M6ZXSJ1A10SCREW, FLAT PHIL, 2-56 X 3/8", SSHrdwr
3MC7SVE1A2SCREW, TRUSS PHIL, 4-40 X 3/16" SSHrdwr
4MH5ZTE1A2Coax,Confrm,#12F-#12F 8" Coax Cable Assy*Coax
5W1MFEJXB2Coax,Confrm,.085,#12F special-SMAM 8"*Coax
6W1MFEZAC1S3 MODIFIED CAL w/ Screw Holes hyp mfixMchFb
7W1MFEZBA1BLOCK CENTER S3 CALMchFb
8W1MFEZCA2BLOCK MID S3 CALMchFb
9W1MFEZEA2BLOCK SIDE S3 CALMchFb
BOM Refreshed:05/11/2020 06:23 PM
